Installationwith stapler
The installation on plywood floor is made with a T-25 stapler.
COPAL FLOOR HEATING CABLE...The Best Comfort
Installationstep to follow
The unheated area must be substracted from the total surface area of the room ...
Programmable Thermostat
Electronic Thermostat complete with GFI # UDG-4999. Programmable with room or floor sensor control
Cable model
Single 'CO'(2mm) or no-return 'Ul'(4mm) heating cable. 'Cl' model with bigger diam. (6 mm et +) available... as heating or snow melting.
The 'CO' COPAL floor heating cable is very thin (3/32(3mm))and does not require a protecting mass of mortar to surround the installation. Thus there is no noticeable change in floor elevation when the system is installed on any existing subfloor.
- Single Heating cable 'CO' (2mm) is 2 watts per li.ft. Indoor use only.
- Twin Heating cable 'UL' (4mm) is 3 watts per li.ft. Indoor use only.
- Single Heating cable 'CL' (6mm) is 5 watts per li.ft. Indoor and outdoor use.
'CO'...The installation on plywood floor is made with a stapler type t-25 with fastener +- 7/16 inch and/or with plastic strapping. Install the cable with a 2 inch interval as main heating or a 3 inches interval as secondary heating. 'CO' cable is available in pre-determined lengths that cover a surface area of 25 to 165 square feet.. his small size does not increases your floor.
'UL'...The installation on plywood floor is made with plastic strapping .Install the cable with a 3 inch interval as main heating or a 4 inches interval as secondary heating 'UL' cable is available in pre-determined lengths that cover a surface area of 20 to 257 square feet... this twin cable has no-return.
'Cl'...install directly on the concrete with metal strapping or in the concrete on the wire mesh. Indoor use, the heating cable space is between 4 and 6 inches , and outdoor use as snow melting the cable space is 1.5 inch. Twelve COPAL models available
The COPAL floor heating cable was developed to fully comply with all applicable C.S.A. certification test requirements and thus is a fully grounded wire with an amoured element and plastic cover...
Downlowd your installation guide pdf format
